Epson FX2190ii Parts
| 100 1730755 HOUSING ASSY.,LOWER;B 100 1750403 1730755 HOUSING ASSY.,LOWER;D 101 1004605 RUBBER FOOT FX-1180+ 102 1715219 GUIDE,FRONT,RIGHT 103 1715218 GUIDE,FRONT,LEFT 104 1715206 KNOB;B 105 1746832 HOUSING,PANEL 106 1715194 OPTICAL TUBE;2 107 1715195 OPTICAL TUBE;3 108 1715198 BUTTON PANEL RIGHT 109 1715202 BUTTON,PANEL,LEFT 110 2176249 BOARD ASSY.,PANEL 111 1730753 HOUSING ASSY.,PANEL 111 1747857 1730753 HOUSING ASSY.,PANEL 112 2181812 HARNESS,COVER OPEN 113 2084079 SWITCH, COVER OPEN 114 1715215 MOUNTING PLATE,COVER OPEN DETECTOR 115 1715225 SUPPORT,FRAME 116 1242257 SHEET, RELEASE, CAP FX-890 117 1745160 HOUSING,UPPER;B ASSY.,ASP 118 1715182 HOLDER,SHEET GUIDE,L;B 119 1715185 HOLDER,SHEET GUIDE,R;B 120 1730748 SHEET GUIDE ASSY. 120 1830382 1730748 SHEET GUIDE ASSY,FX-2190II;IEI 121 1745158 COVER,PRINTER ASSY.,ASP 122 1745159 COVER,PRINTER,REAR ASSY.,ASP 123 1730750 COVER ASSY.,FRONT;B 124 1730751 COVER ASSY.,FRONT SUB 125 1715224 SPACER,KNOB 126 1715220 GUIDE,STACKER 127 1729074 WING;EBCK 128 2181204 HARNESS,INLET,W 130 1715214 SHEET,SHIELD PLATE 131 1726286 LABEL,ACCESSORY 200 2176241 BOARD ASSY., MAIN 300 2185288 POWER SUPPLY UNIT 300 2204579 2185288 POWER SUPPLY UNIT 350 1715207 HOLDER,AC CABLE 351 1715212 SHIELD PLATE 351 1775106 1715212 SHIELD PLATE;B 352 2167302 FAN ASSY,B 353 1715208 GROUNDING PLATE,I/F 354 2176252 HARNESS,PS 358 1715213 SHIELD PLATE,UPPER 358 1775107 1715213 SHIELD PLATE,UPPER;B 501 1715111 FRAME ASSY.,MAIN,RIGHT 502 1715110 FRAME ASSY.,MAIN,LEFT 503 2181780 MOTOR ASSY.,CR 504 1745165 RD ASSY.,ASP 505 1732556 SHEET,CR,FFC 506 1717825 SHEET,CR,CONNECTOR 507 2185396 CABLE,HEAD 509 1039973 GROUNDING WIRE,PLATEN 510 1286422 C-RING,5103-31,F/UC-3C 511 2181781 MOTOR ASSY.,PF 512 1076285 LEAF SPRING (8.2X0.25X15) (B101253990) 513 1076264 PLAIN WASHER (8X0.5X15) 514 1738457 SPUR GEAR,36;B 514 1031612 1738457 PLATEN GEAR,LQ-2070,LQ-2170,FX-2170FX-88 515 1031702 SPRING PIN 2X12 516 2185421 HARNESS,PE,FRONT 517 1836554 PAPER EJECT ASSY 517 1730742 1836554 PAPER EJECT ASSY. 517 1881905 1836554 PAPER EJECT ASSY;B 518 1425358 COMPRESSION SPRING,0.13 519 1426965 HOLDER,ROLLER,PAPER EJECT,DRIVEN;B 520 1425333 ROLLER,PAPER EJECT,DRIVEN 521 2185420 HARNESS,PG 522 2116975 DETECTOR,LEAF,B2 522 2014328 2116975 CONNECTOR SWITCH LQ-2170 523 1724325 ROLLER,PF,DRIVEN,REAR 524 1715147 EXTENSION SPRING,1.1 525 1724323 PAPER,GUIDE 526 1724324 SHAFT,RELEASE 527 1519930 HOLDER,PF,ROLLER,RIGHT 528 2185422 HARNESS,PE,REAR 530 1724327 PAPERGUIDE,MIDDLE 532 1005213 ROLLER, PF, DRIVEN, LOWER FX1180+ 533 1737103 ROLLER ASSY PF.,ASP 534 1745164 PAPER GUIDE,SUPPORT ASSY.,ASP 535 1025363 COMPRESSION SPRING,10.8 536 1745167 CARRIAGE ASSY.,ASP 537 1715117 SLIDER,CR 538 1732555 SHAFT,CR,GUIDE 539 2071496 DETECTOR, PE FRONT FOR FX1180+ IMPACT PR 540 1715140 LEVER,DETECTOR,PE,REAR 541 2091555 BOARD ASSY.,PE 541 2207418 2091555 BOARD ASSY.,SNS 542 1408766 TRACTOR,LEFT EDGB 542 1001108 1408766 TRACTOR LEFT (LOCK LEVER GRAY) FX-870 543 1408768 TRACTOR,RIGHT EDGB 544 1676876 SHAFT,TF,DRIVE;B 544 1038503 1676876 SHAFT, TF, DRIVE FOR FX1180+ IMPACT PRIN 545 1677254 SHAFT,TR,GUIDE;B 545 1005251 1677254 SHAFT, TR, GUIDE FOR FX1180+ IMPACT PRIN 546 1715169 FRAME,TR,LEFT 547 1715174 FRAME,TR,RIGHT 548 1715175 LEVER,TR,RIGHT 549 1715173 LEVER,TR,LEFT 550 1538301 PAPER SUPPORT 550 1025296 1538301 PAPER SUPPORT 551 1039507 SPUR GEAR FOR FX1180+ IMPACT LQ-2170 551 1044973 1039507 SPUR GEAR, 20 LQ-1170 IMPACT PRINTER 552 1283665 E-RING 6 F/UC -3C 552 B150300911 1283665 RETAINING RING TYPE-E (6) LQ-2170 IMPACT 553 1590165 FIX MINI CLAMP JCF-2S 554 1724326 PAPERGUIDE,FRONT 555 1715106 HOLDER,LEVER,GAP 556 1724344 COVER,PAPER EJECT 557 1745162 FRAME,PAPER EJECTASSY.,ASP 559 1232294 BUSHING, PARALLEL, ADJUST FX-890 560 1715103 HOLDER,PULLEY,DRIVEN 561 1715153 SPUR GEAR,15 562 1004929 11.5 SPUR GEAR 563 1715105 LEVER,GAP,SUB 564 1724345 ROLLER ASSY.,PAPER EJECT,DRIVE 568 1745169 HOLDER,CABLE,HEAD ASSY.,ASP 569 1730746 ROLLER ASSY.,DRIVE 570 1724322 PLATEN 571 1715104 LEVER,GAP,ADJUST 572 1232297 BUSHING,8,RIGHT FX-890 573 1724328 COVER,PLATEN;B 574 1232296 BUSHING,8,LEFT FX-890 575 1715114 RIBBON MASK 576 1282417 E-RING,4,F/UC-3CP 576 1074107 1282417 RETAINING RING 576 B150300711 1282417 RETAINING RING TYPE-E (4) 577 1250538 BASE RUBBER FX-890 578 1724313 FRAME,REAR 579 1745163 FRAME,FRONT ASSY.,ASP 580 1715100 FRAME,SUB,RIGHT 581 1715226 HOLDER,BASE RUBBER 584 1745168 HOLDER,CABLE ASSY.,ASP 585 2182610 HARNESS,RE 586 1715108 HOLDER,CABLE,FRAME 587 1005185 MOUNTING PLATE, MOTOR, CR FOR FX1180+ IM 588 1715113 HOLDER,RIBBON MASK 589 1715120 MOUNT,SLIDER 590 1715155 LEVER,RELEASE;B 591 1028357 CAM,CLUTCH,TRACTOR,LQ-2070 LQ-2070 592 2176250 FFC,PANEL 593 1715146 COMBINATION GEAR,8,31.5 593 1749476 1715146 COMBINATION GEAR,8,31.5 594 1005224 SPUR GEAR FOR FX1180+ IMPACT PRINTER 595 1013093 SPUR GEAR FX-880 595 1829107 1013093 SPUR GEAR,34.5;B 596 1005226 SPUR GEAR, 34 FOR FX1180+ IMPACT PRINTER 597 1715154 SPUR GEAR,15;B 598 1028359 INTERMITTENT GEAR LQ-2070 599 1235585 LEVER, RELEASE, TRANSMISSION FX-2180 IMP 600 1080933 EXTENSION SPRING, 16.45 IMPACT PRINTER 601 1005232 COMPRESSION SPRING, 200 602 1721386 COVER,CRHP 603 2185419 HARNESS,HP 604 1730741 TRACTOR ASSY. 605 1730743 PLATEN ASSY. 606 1745166 PAPER GUIDE ASSY. REAR,ASP 613 1296960 SHAFT,MOUNT PLATE,CR-3C 700 1737097 HEAD KIT ASP NON FIG 1091150 THICKNESS GAUGE SET (19) #F518 NON FIG B776702201 1091150 THICKNESS GAUGE SET (19) #F518 NON FIG 2112512 POWER CABLE, LATIN AMERICA NON FIG 3110865 SOFTWARE DISC,EA |  |
 | |
 |
